Left Rear Brake Wear Sensor Connector End View
Left Rear Brake Wear Sensor Connector End View
BRAKE WEAR SENSOR-LEFT REAR
Courtesy of DAIMLERCHRYSLER CORP.
CAV
CIRCUIT
FUNCTION
1
16BR
GROUND
2
16BR/WT
BRAKE WEAR SENSOR SIGNAL
Courtesy of DAIMLERCHRYSLER CORP.
