Ash Receiver Lamp Connector End View

ASH RECEIVER LAMP

GCVA580014Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 18GY/DG/RD LAMP DRIVER
3 18BR GROUND
