Accelerator Pedal Position Sensor (OBD) Connector End View
ACCELERATOR PEDAL POSITION SENSOR (OBD)
| CAV | CIRCUIT | FUNCTION |
| 1 | 18BL/DG | ACCEL PEDAL POSITION SENSOR SIGNAL NO. 1 |
| 2 | 18BR/GY | ACCEL PEDAL POSITION SENSOR GROUND NO. 2 |
| 3 | 18GY/DG | ACCEL PEDAL POSITION SENSOR SIGNAL NO. 2 |
| 4 | 18BL/RD | ACCEL PEDAL POSITION SENSOR 5 VOLT SUPPLY |
| 5 | 18BR/BL | ACCEL PEDAL POSITION SENSOR GROUND NO. 1 |
