Interior Lighting Connector Connector End View

INTERIOR LIGHTING CONNECTOR

GCVA580191Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 16RD/YL FUSED B(+)
2 16DG INTERIOR LAMPS DRIVER
3 16BR GROUND
4 16YL INTERIOR LIGHT SWITCH OUTPUT
