Additional Heat Exchanger Connector End View
ADDITIONAL HEAT EXCHANGER
 Courtesy of DAIMLERCHRYSLER CORP.
|
| CAV |
CIRCUIT |
FUNCTION |
| A |
12BR |
GROUND |
| B |
12RD/BL |
AUXILIARY HEATER RELAY OUTPUT |
| C |
16VT/BL |
ADDITIONAL HEAT EXCHANGER CAV C TO HEAT EXCHANGER SWITCH CAV 7 |
| D |
16VT/YL |
ADDITIONAL HEAT EXCHANGER CAV D TO HEAT EXCHANGER SWITCH CAV 4 |
