Exhaust System: Tailpipe: Description

Fig 1: LOCATING EXHAUST PIPE TO MANIFOLD CONNECTION - (3.9L/5.9L)

Courtesy of DAIMLERCHRYSLER CORP.

1 - EXHAUST PIPE INSULATOR

2 - EXHAUST PIPE

3 - EXHAUST PIPE-TO-MUFFLER CLAMP

4 - MUFFLER

5 - MUFFLER INSULATOR

The tailpipe is made of stainless steel and attaches to the muffler.
