Standard Procedure - Lubrication

Periodic lubrication of the suspension system is required. refer to the owner's manual for schedules.

The following lubrication points on the suspension system must be lubricated periodically (Fig 1 ).

Front Suspension:

Rear Suspension:

Lubricate each point until a slight swelling is noticed in the seal boot. Do not overfill the seal boots.

Fig 1: Identifying Lubrication Points - Overhead View

Courtesy of DAIMLERCHRYSLER CORP.
