Intake Manifold Tightening

Tighten bolts in sequence shown in diagram to 35 ft. lbs. (318" & 360") or to 40 ft. lbs. (400" & 413").

Fig 1: Intake Manifold Tightening Sequence

Courtesy of CHRYSLER GROUP, LLC
