Right Bank
Observe the following precautions when working on fuel systems: No sparks, open flames or smoking. Avoid inhaling and swallowing fuel. Avoid eye and skin contact with fuel. Pour fuels only into suitable and appropriately marked containers. Wear protective clothing. Failure to observe these precautions may result in fire, explosion, property damage, and serious or fatal injury.
High-pressure fuel lines deliver fuel under extreme pressure from the injection pump to the injectors. This maybe as high as 1800 bar (26, 206 psi). Use extreme caution when inspecting for high-pressure fuel leaks. Inspect high-pressure fuel leaks with a sheet of cardboard. Wear safety goggles and adequate protective clothing when servicing fuel system. Fuel under this amount of pressure can penetrate skin causing serious or fatal injury.
- Disconnect the negative battery cable.
- Remove the EGR tube. Refer to TUBE, EXHAUST GAS RECIRCULATION (EGR), REMOVAL .
- Using shop air, clean the area surrounding the fuel injector.
- Lift up on locking retaining tab (2) to unlock the lock.
- Disconnect the fuel return hose (3) by wiggling hose free at the fuel injector (4).
- Disconnect the fuel injector harness connector (1).
- Remove the high pressure fuel tubes. Refer to TUBE(S), FUEL, REMOVAL .
- Remove the fuel injector hold down bolt (2), washer (3), and retaining claw (4).
- Using your hand, pull fuel injector (1) straight up from cylinder head for removal. Discard lower sealing washer and place a protective cap over the nozzle and cylinder head.
- If injector can't be removed by hand, install the (special tool #VM.10358A, Remover, Fuel Injector) (1) to remove the fuel injector (2). Discard lower sealing washer and place a protective cap over the nozzle.
