Backup Lamp Switch (Diesel) Connector End View
Backup Lamp Switch (Diesel) Connector End View
SWITCH-BACKUP LAMP - 2 WAY (DIESEL)
Courtesy of CHRYSLER CORP.
CAV
CIRCUIT
FUNCTION
1
Z931 20BK
GROUND
2
T22 20YL/VT
BACKUP LAMP SWITCH SIGNAL
