Component Locations: Sensors: 3.3L/3.8L

Fig 1: Locating Camshaft Position Sensor
G05552125Courtesy of CHRYSLER


Fig 1: Locating Camshaft Position Sensor
G04762139Courtesy of CHRYSLER


Fig 1: Locating Inlet Air Temperature Sensor
G04763098Courtesy of CHRYSLER


Fig 1: Locating MAP Sensor
G04763100Courtesy of CHRYSLER


Fig 1: Locating O2 Sensor
G04762142Courtesy of CHRYSLER


Fig 1: Locating Idle Air Control Valve And TP Sensor
G04549203Courtesy of CHRYSLER
