Engine Mount - Right

WARNING: This page is about a different variant/trim than selected.
Fig 1: Removing/Installing Right Engine Mount (V6)
GC0060236Courtesy of CHRYSLER LLC
  1. Position right engine mount (5).
  2. Install 2 engine mount bolts and tighten to 75 N.m (55 ft. lbs.).
  3. Install engine mount bracket.
  4. Install 3 engine mount bracket bolts (1) and tighten bolts to 68 N.m (50 ft. lbs.).
  5. Install 2 engine mount bracket bolts (2)
  6. Remove jack.
  7. Install power steering reservoir. Refer to INSTALLATION .
