Rear-End Collision SRS Operation

Fig 1: Rear-End Collision SRS Operation
GC0035673Courtesy of CHRYSLER LLC

When the ORC registers sudden acceleration which exceeds the forward threshold value a check is made to determine which front seat belts are fastened. The ORC then activates only the SBTs which have fastened seat belts. The driver/passenger airbags are not activated unless a frontal collision which exceeds the stage two threshold is detected.
