Diagnostic Test

WARNING: This page is about a different car, the 2009 Dodge Sprinter. However, it is still accessible from the selected car via links, so may be relevant.

INTEGRATED POWER MODULE

Courtesy of CHRYSLER LLC
1. Turn the ignition off.
2. Replace the Park Lamp relay with and known good relay.
3. With the scan tool, clear all BCM DTCs.
4. Turn the Park Lamps ON then OFF.
5. With the scan tool, read the DTCs.
  Does the scan tool read: 9001-LEFT PARKING LAMP CONTROL CIRCUIT HIGH-BCM?

  Yes
  - Replace the Body Control Module in accordance with the service information.
  - Perform the BODY VERIFICATION TEST. See DTC-Based Diagnostics/MODULE, Body Control (BCM) - Standard Procedure .
  No
  - Test complete.
  - Perform the BODY VERIFICATION TEST. See DTC-Based Diagnostics/MODULE, Body Control (BCM) - Standard Procedure .
