DTC 9094: Body Control Module Ground Disconnected: Notes

WARNING: This page is about a different car, the 2007 Dodge Sprinter. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Body Control Module Ground Circuit Schematic

Courtesy of CHRYSLER LLC

For complete wiring diagrams refer to SYSTEM WIRING DIAGRAMS article.

When Monitored:
With the ignition on.
Set Condition:
The Body Control Module (BCM) does not detect a ground circuit.

Possible Causes
GROUND CIRCUIT OPEN
BODY CONTROL MODULE
