Removal - SRT

Fig 1: Removing/Installing Cooling Fan Module
GC0033982Courtesy of DAIMLERCHRYSLER CORP.
  1. Disconnect the negative battery cable.
  2. Disconnect the radiator fan control module harness connector located next to the air pump in the left front of the vehicle.
  3. Remove the retaining nuts at the top and bottom of the cooling fan module (1).
  4. Remove the cooling fan module from the engine compartment.
