Section 238 (DECKLID, Hatch, Liftgate &Tailgate): Latch: Removal

WARNING: This page is about a different car, the 2004 Dodge Grand Caravan, 2004 Dodge Caravan, and 2004 Chrysler Town & Country. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove liftgate trim panel.
  2. Disengage outside handle link from clip on latch.
  3. Disconnect wire connector from liftgate latch (Fig 1 ).
    Fig 1: Removing Striker From Vehicle
    G03585913Courtesy of DAIMLERCHRYSLER CORP.
  4. Remove screws attaching latch to liftgate.
  5. Remove latch from vehicle.
