Automatic Shut Down Relay: Installation

WARNING: This page is about a different car, the 2004 Dodge Pickup and 2004 Dodge Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

The ASD relay is located in the Power Distribution Center (PDC) (Figure). Refer to label on PDC cover for relay location.

  1. Install relay to PDC.
  2. Install cover to PDC.
