Home >> Chrysler >> 2004 >> Pacifica FWD >> Repair and Diagnosis >> Electrical >> Gauges >> Instrument Panel >> Instrument Panel End Cap >> Installation

Instrument Panel End Cap: Installation

  1. Place end cap into position.
  2. Apply press on instrument panel end cap to engage the locking tabs (Figure ).
  3. Close front door.
