Exterior/Interior Trim: Body: Sunroof: Installation: Installation

Place motor into position Figure).
Install three screws attaching motor to bracket. Tighten screws to 3 N.m (27 in. lbs.) torque.
NOTE: Hold electronics module to motor bracket when inserting motor shaft to avoid disengaging drive cables.
Connect sunroof electrical connector.
Tape wires to drive cables to prevent rattles.
Install headliner(Refer to INSTALLATION ).
Install sunroof control switch(Refer to INSTALLATION ).
Test sunroof operation, adjust sunroof glass as necessary(Refer to INSTALLATION ).
Install sunroof opening lace(Refer to INSTALLATION ).
