Lock Cylinder: Removal
WARNING: This page is about a different car, the 2003 Dodge Intrepid, 2003 Chrysler Intrepid, 2003 Chrysler Concorde, and 2003 Chrysler 300M. However, it is still accessible from the selected car via links, so may be relevant.
- Remove door trim panel. (Refer to REMOVAL
).
- Remove water shield, as necessary
- Raise door glass.
- Disengage clip holding lock link to lock cylinder.
- Disconnect link from lock cylinder.
- Disconnect clip attaching lock cylinder to door handle.
- Pull lock cylinder from door handle (Figure
).
