Water Pump - 3.5L: Installation

WARNING: This page is about a different car, the 2003 Dodge Intrepid, 2003 Chrysler Intrepid, 2003 Chrysler Concorde, and 2003 Chrysler 300M. However, it is still accessible from the selected car via links, so may be relevant.

Clean all O-ring surfaces on pump and cover.
Apply Mopar(R) Dielectric Grease or the equivalent silicone grease to the O-ring to facilitate assembly. Install new O-ring on water pump (Fig 1 ).

Fig 1: Installing Water Pump - 3.5L
Courtesy of DAIMLERCHRYSLER CORP.
Position water pump to engine.
Install mounting bolts and tighten to 12 N.m (105 in. lbs.).
Install timing belt. Refer to appropriate ENGINE article.
Install accessory drive belts (Refer to ACCESSORY DRIVE ).
Fill cooling system.
