Installation Procedure

  1. GM5375380Courtesy of GENERAL MOTORS COMPANY

    Rear Window (1) - Install - Adhesive Installation of Rear Windows

  2. Connect the defrost tab electrical connectors.
  3. Install the rear closure center applique. Rear Closure Center Applique Replacement
  4. Install the liftgate panel ventilating molding. Liftgate Panel Ventilating Molding Replacement
  5. Remove the tape.
  6. Remove any remaining adhesive residue with a 50/50 mixture by volume of isopropyl alcohol and clean drinkable water. Wipe the surface dry with a clean lint-free towel.
