Front Grille Replacement

GM4743502

Courtesy of GENERAL MOTORS COMPANY

Callout

Component Name

Preliminary Procedure
Front Bumper Fascia Energy Absorber Replacement

1

Front Grille Clip [2x]

2

Front Grille

Procedure

Place the bumper fascia face down on a clean protected surface.
Reposition the front view camera.
Using a suitable trim tool, release the locking tabs while carefully pulling the front upper grille from the front fascia.
Transfer components as necessary.

NOTE:

Each individual front bumper fascia tab must be secure to each slot in the radiator grille prior to reassembly of the fascia to the vehicle.
