Removal Procedure

  1. Remove Front Brake Rotor - Front Brake Rotor Replacement
    2. Fig 1: Ball Joint Separator
    GM3512309Courtesy of GENERAL MOTORS COMPANY
  2. Use the CH-43631  separator (1) to remove the wheel stud from the flange on the hub assembly.

    DISCARD the stud.
