Windshield Washer Solvent Container Replacement

Preliminary Procedures

1. Remove Front Wheelhouse Liner. Refer to Front Wheelhouse Liner ReplacementFront Wheelhouse Liner Replacement (ZL1)
2. Remove Windshield Washer Solvent Container Filler Tube. Refer to Windshield Washer Solvent Container Filler Tube Replacement
3. Place a suitable drain pan under the windshield washer pump area to recover the windshield washer solvent when the windshield washer pump hose is disconnected.

Procedure

1. Disconnect windshield washer nozzle hose from the windshield washer pump hose.
2. Disconnect the electrical connector.
3. Remove the windshield washer solvent container from the vehicle.
4. Drain the windshield washer solvent into a suitable clean container.
5. Transfer components as necessary.
