Front Seat Belt Retractor Replacement

Fig 1: Front Seat Belt Retractor

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
WARNING: Refer to SIR Warning . Preliminary Procedures Disable the supplemental inflatable restraint (SIR) system. Refer to SIR Disabling and Enabling . Remove the center pillar lower trim panel. Refer to Center Pillar Lower Trim Panel Replacement . Remove the center pillar upper trim panel. Refer to Center Pillar Upper Trim Panel Replacement . Remove the front seat belt anchor plate tensioner cover and bolt. Refer to Front Seat Belt Anchor Plate Tensioner Replacement .
1	Front Seat Belt Anchor Bolt CAUTION: Refer to Fastener Caution . Tighten 40 N.m (30 lb ft)
2	Front Seat Belt Retractor Retainer
3	Front Seat Belt Anchor Plate Tensioner Bolt Tighten 6 N.m (53 lb in)
4	Front Seat Belt Retractor Bolt Tighten 40 N.m (30 lb ft)
5	Front Seat Belt Retractor Assembly Procedure Remove the retractor from the body panel.
