Input and Output Speed Sensor Assembly Installation
Input and Output Speed Sensor Assembly Installation
| Callout | Component Name |
|---|---|
| 1 | A/Trans Input and Output Speed Sensor Wiring Harness Clip (Qty: 2) |
| 2 | A/Trans Input and Output Speed Sensor Assembly |
| 3 | Bolt M6 x 20 (Qty: 2)
CAUTION:
Refer to Fastener Caution . Tighten 12 N.m (106 lb in) |
