Installation Procedure

WARNING: This page is about a different car, the 2013 Chevrolet Spark. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Mode Valve Link
    GM2754797Courtesy of GENERAL MOTORS COMPANY
  1. Install the mode valve link (1).
  2. Connect the stop lamp switch connector.
  3. Install the left side floor air outlet duct. Refer to Floor Air Outlet Duct Replacement - Left Side (Left Hand Drive) .
