Back of Engine Compartment

Back of Engine Compartment

Items
1:  B1 A/C Refrigerant Pressure Sensor B1 A/C Refrigerant Pressure Sensor
2:  B1C A/C Low Side Pressure Sensor
3:  G35 Hybrid/EV Electronics Coolant Pump G35 Hybrid/EV Electronics Coolant Pump
4:  G37 Hybrid/EV Battery Pack Coolant Pump G37 Hybrid/EV Battery Pack Coolant Pump
Fig 1: Back of Engine Compartment
GM3216441Courtesy of GENERAL MOTORS COMPANY
