| 1 |
Right Front Impact Sensor-Located under the hood at the front right side of the vehicle |
| 2 |
Vehicle Battery-Located at the front left of the engine compartment |
| 3 |
Front Hood Assist Rod-A gas shock located under the front hood on the passenger side |
| 4 |
Passenger Instrument Panel Air Bag-Located at the top right under the instrument panel |
| 5 |
Right Roof Rail Air Bag-Located under the headliner, extending from the passenger front windshield pillar to the passenger rear windshield pillar |
| 6 |
Right Front Side Impact Sensor (SIS)-Located behind door panel on the passenger front door |
| 7 |
Inflatable Restraint Sensing and Diagnostic Module (SDM)-Located underneath the passenger front seat under the vehicle carpet |
| 8 |
Passenger Presence System (PPS)-Located on the passenger front seat underneath the seat bottom trim |
| 9 |
Passenger Seat Belt Anchor Pretensioner-Located on the outboard side of the passenger seat |
| 10 |
Passenger Seat Side Air Bag-Located on the seat back of passenger seat |
| 11 |
Passenger Seat Belt Retractor Pretensioner-Located under the trim near the bottom of the center pillar on the passenger side of vehicle in the Sedan |
| 12 |
Inflator Module for Right Roof Rail Air Bag-Located behind the garnish molding on the upper rear pillar |
| 13 |
Rear Hood Assist Rod-A gas shock located under the rear truck lid on the passenger side |
| 14 |
Rear Hood Assist Rod-A gas shock located under the rear truck lid on the driver side |
| 15 |
Inflator Module for Left Roof Rail Air Bag-Located behind garnish molding on the upper rear pillar |
| 16 |
Driver Seat Belt Retractor Pretensioner-Located under the trim near the bottom of the center pillar on the driver side of vehicle in the Sedan |
| 17 |
Driver Seat Side Air Bag-Located on the seat back of driver seat |
| 18 |
Driver Seat Belt Anchor Pretensioner-Located on the outboard side of the driver seat |
| 19 |
Left Front Side Impact Sensor (SIS)-Located behind door panel on the driver front door |
| 20 |
Left Roof Rail Air Bag-Located under the headliner, extending from the driver front windshield pillar to the driver rear windshield pillar |
| 21 |
Driver Steering Wheel Air Bag-Located on the steering wheel |
| 22 |
Front Hood Assist Rod-A gas shock located under the front hood on the driver side |
| 23 |
Left Front Impact Sensor-Located under the hood at the front left side of the vehicle |
