Battery Negative Cable Disconnection and Connection

Fig 1: Battery Negative Cable
GM2632492Courtesy of GENERAL MOTORS COMPANY
Battery Negative Cable Disconnection and Connection

Callout Component Name
1 Battery Negative Post Clamp
CAUTION:

Refer to Fastener Caution .
2 Battery Negative Cable
