HVAC Module Components (With C68 - AUTO, ELECTRONIC CONTROLS)

HVAC Module Components (With C68 - AUTO, ELECTRONIC CONTROLS)

Items
1:  T4H Digital Radio Antenna
2:  K9 Body Control Module K9 Body Control Module X1K9 Body Control Module X2K9 Body Control Module X3K9 Body Control Module X4K9 Body Control Module X5K9 Body Control Module X6K9 Body Control Module X7
3:  K77 Remote Control Door Lock Receiver K77 Remote Control Door Lock Receiver (AP3)

Fig 1: HVAC Module Components (C68)

Courtesy of GENERAL MOTORS COMPANY
