Power Steering Fluid Reservoir Replacement

Fig 1: Power Steering Fluid Reservoir

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedures Remove as much power steering fluid from the remote power steering fluid reservoir as possible. Place drain pans under the vehicle as needed.
1	Hose Clamp Procedure Compress the power steering fluid reservoir outlet and inlet hose clamp from the power steering fluid reservoir. Remove outlet and inlet hose from power steering fluid reservoir.
2	Power Steering Fluid Reservoir Bolt CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
3	Power Steering Fluid Reservoir Procedure Fill and bleed the power steering system. Refer to Power Steering System Bleeding . NOTE: Clean any excess power steering fluid from the vehicle.
