Fuel Pump Cover Replacement

Fig 1: Fuel Pump Cover
GM2548655Courtesy of GENERAL MOTORS COMPANY
Fuel Pump Cover Replacement

Callout Component Name
1 Fuel Pump Cover Fastener (Qty: 3)
CAUTION:

Refer to Fastener Caution .


Tighten
10 N.m(89 lb in)
2 Fuel Pump Cover
3 Fuel Pump Insulator
