Engine Identification

Fig 1: Engine Identification Code On Cylinder Block
GM1945826Courtesy of GENERAL MOTORS COMPANY
IMPORTANT:

When a short block engine is installed, the engine number must be marked on the cylinder block before installing the engine.

The engine identification code is embossed on the flattened area of the cylinder block, arrow, at the transmission side.
