Instrument Panel Compartment Door Latch Replacement

WARNING: This page is about a different car, the 2010 Cadillac SRX. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Locating Instrument Panel Compartment Door Latch
GM2445955Courtesy of GENERAL MOTORS CORP.
Callout Component Name
Preliminary Procedures:
Remove the instrument panel center compartment assembly. Refer to Instrument Panel Center Compartment Replacement .
1 Instrument Panel Center Compartment Door Latch

Procedure

  1. Open the compartment door assembly.
  2. Squeeze the tabs securing the latch to the compartment assembly and push the latch outward removing it from the compartment.
