Coolant Recovery Reservoir Replacement

WARNING: This page is about a different car, the 2010 Chevrolet Camaro. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Coolant Recovery Reservoir

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedures Drain the cooling system. Refer to Cooling System Draining and Filling (LS3, L99 Static Fill) or Cooling System Draining and Filling (LLT Static Fill) or Cooling System Draining and Filling (GE 47716) . Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the radiator overflow hose. Refer to Radiator Overflow Hose Replacement (LLT) or Radiator Overflow Hose Replacement (LS3, L99) .
1	Coolant Recovery Reservoir Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 17 N.m (13 lb ft)
2	Coolant Recovery Reservoir

Callout

Component Name

Preliminary Procedures

Drain the cooling system. Refer to Cooling System Draining and Filling (LS3, L99 Static Fill) or Cooling System Draining and Filling (LLT Static Fill) or Cooling System Draining and Filling (GE 47716) .
Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
Remove the radiator overflow hose. Refer to Radiator Overflow Hose Replacement (LLT) or Radiator Overflow Hose Replacement (LS3, L99) .

Coolant Recovery Reservoir Bolt (Qty: 2)

CAUTION: Refer to Fastener Caution .

Tighten: 17 N.m (13 lb ft)

Coolant Recovery Reservoir
