Installation Procedure

WARNING: This page is about a different car, the 2006 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Identifying Air Inlet Door & Recirculation Housing
    GM1235729Courtesy of GENERAL MOTORS CORP.
  1. Install the recirculation door to the air inlet housing.
  2. Install the air inlet assembly. Refer to Air Inlet Assembly Replacement .
