Installation Procedure

WARNING: This page is about a different car, the 2005 Chevrolet Optra5 and 2005 Chevrolet Optra. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Hood Release Handle And Screws
    GM1309221Courtesy of GENERAL MOTORS CORP.
  1. Position the hood latch in the location marked during removal.
    2. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the hood latch with the bolts.

    Tighten:  Tighten the hood latch bolts to 8 N.m (71 lb in)  .
