Installation Procedure

WARNING: This page is about a different car, the 2005 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Installing Deck Lid Switch In Door Trim Panel
    GM1235710Courtesy of GENERAL MOTORS CORP.
  1. Connect the electrical connector to the switch.
  2. Install the deck lid switch to the door trim panel.
  3. Install the door trim pad. Refer to Trim Panel Replacement - Side Front Door in Interior Trim.
