Installation Procedure

Fig 1: View Of Blower Motor Resistor And Screws

Courtesy of GENERAL MOTORS CORP.

NOTE: Refer to Fastener Notice in Cautions and Notices.

Install the resistor into the heater/air distributor case with the screws.
Tighten: Tighten the blower motor resistor screws to 1.2 N.m (11 lb in) .
Connect the electrical connector at the resistor.
Connect the negative battery cable.
Confirm the proper performance of the blower.
Replace the glove box. Refer to Instrument Panel Storage Compartment Replacement in Instrument Panel, Gauges and Console.
