Cruise Control Schematics

WARNING: This page is about a different car, the 2008 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Cruise Control Schematic
GM1991927Courtesy of GENERAL MOTORS CORP.
