Installation Procedure

WARNING: This page is about a different car, the 2004 GMC Safari and 2004 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Push the support rod retainer into place.
  2. Insert the retainer tab into the slot in order to install the support rod to the vehicle.
    Fig 1: Expanded View Of Hood Hold-Open Rod
    GM321602Courtesy of GENERAL MOTORS CORP.
    NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the support rod-to-radiator support bolt.

    Tighten:  Tighten the support rod to radiator support bolts to 15 N.m (11 lb ft).

  4. Lower the hood.
