Installation Procedure

  1. Install the battery into the vehicle. Position the battery into the carrier.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  2. Install the battery hold down bracket to the carrier. Secure the bracket with 2 nuts.

    Tighten

    1. Tighten the battery hold down bracket bolt to 8 N.m (71 lb in).
  3. Connect the positive (+) battery cable (3) to the positive (+) battery terminal.

    Tighten

    1. Tighten the positive battery cable-to-battery terminal to 15 N.m (11 lb ft).
    Fig 1: Installing Battery Hold Down Bracket To Carrier
    G01470767Courtesy of GENERAL MOTORS CORP.
  4. Install the negative (-) battery cable (1) to the negative (-) battery terminal.

    Tighten

    1. Tighten the negative battery cable-to-battery terminal to 15 N.m (11 lb ft).
