Installation Procedure

  1. Install a replacement stud in the wheel hub.
  2. Add enough washers (3) in order to draw the stud into the hub (2).
  3. Install the wheel nut (1) with the flat side against the washers (3).
  4. Tighten the wheel nut (1) until the wheel stud is fully seated against the hub flange.
  5. Back off the wheel nut (1) and remove the washers (3).
  6. Install the brake rotor. Refer to BRAKE ROTOR .
  7. Install the brake caliper and bracket. Refer to BRAKE CALIPER .
  8. Install the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  9. Lower the vehicle.
    Fig 1: Identifying Wheel Nut & Washers
    G01513503Courtesy of GENERAL MOTORS CORP.
