Transfer Case - NVG 236-NP8 (Unit Repair): Specifications
Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Case Bolts | 37 N.m | 27 lb ft |
| Clutch Lever Pivot Pins | 40 N.m | 30 lb ft |
| Drain Plug | 20 N.m | 15 lb ft |
| Encoder Motor Bolts | 20 N.m | 15 lb ft |
| Fill Plug | 20 N.m | 15 lb ft |
| Shift Detent Spring Bolt | 17 N.m | 13 lb ft |
| Vehicle Speed Sensors | 15 N.m | 11 lb ft |
