Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Press the bulb into the license lamp socket.
  2. Install the license lamp lens to the liftgate.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  3. Install the screws to the license lamp lens.

    Tighten

    Tighten the screws to 2 N.m (18 lb in).

    Fig 1: Installing License Lamp Bulb And License Lamp Lens To License Lamp
    G01534116Courtesy of GENERAL MOTORS CORP.
