Installation Procedure

  1. Install the inflatable restraint steering wheel module coil to the steering shaft.
  2. Install the retaining ring.
  3. Route the lower coil wiring harness along steering column and install the necessary wiring harness straps.
  4. Connect the radio steering wheel controls inline connector C205.
  5. Install the upper and lower steering column shrouds.
  6. Install the steering wheel. Refer to STEERING WHEEL REPLACEMENT .
  7. Install the inflatable restraint steering wheel module. Refer to Inflatable Restraint Steering Wheel Module Replacement .
  8. Enable the SIR system. Refer to Enabling the SIR System .
    Fig 1: Installing Upper/Lower Steering Column Shrouds & Radio Steering Wheel Controls Inline Connector
    G01814806Courtesy of GENERAL MOTORS CORP.
