Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Snap the speaker into the lock module.
  2. Connect the electrical connector.
  3. Install the front door water deflector. Refer to WATER DEFLECTOR REPLACEMENT - FRONT DOOR  in Doors.
  4. Install the front door trim panel. Refer to TRIM PANEL REPLACEMENT - SIDE FRONT DOOR  in Doors.
    Fig 1: Snapping Speaker Into Lock Module
    G01534314Courtesy of GENERAL MOTORS CORP.
